E/I driver transformer, made of
M4 laminations
 code: TRANS-***
C-core driver transformer, made of
SR48 Nickel or R36 Nickel or High B laminations
code: TRANS-***
Want to know more about C-cores? Then read Peter Qvortrup and Andrew Grove`s article. Click here.
|
It is becoming increasingly obvious that applying transformer at every stage of an amplifier yields a great benefit in sound quality, provided off course the transformer in question is of an appropriate quality and design.
Replacing any coupling capacitor with a well designed and correctly matched driver or interstage transformer yields an almost shocking improvement in sound and should be tried to fully understand what a good wideband transformer has to offer.
All Copper - Copper transformers have copper lead out wires, Copper - Silver have copper on the primary and Audio Note silver leadout wires on the secondary and silver naturally silver all round.
Driver transformers 1:1 ratio to suit ECC82, 5687, E182CC, 6SN7 and 6463
|
| Order Code |
Suggested Valves |
Winding: Primary - Secondary |
Core material |
Standing Current |
Step-down Ratio |
Price each (exc. vat) |
| TRANS-013 |
ECC82,5687,E182CC,6SN7,6463 |
Copper-Copper |
M4 I/E |
10mA |
1:1 |
£111.00 |
| TRANS-013/01-AN |
" " |
" " |
AN Ultra HiB |
" " |
" " |
£397.00 |
| TRANS-013/01-A |
" " |
" " |
High B,0.2mm |
" " |
" " |
£221.00 |
| TRANS-013/01-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£526.00 |
| TRANS-013/01-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£686.00 |
| TRANS-013/02-AN |
" " |
Copper - Audio Note™ silver |
AN Ultra HiB |
" " |
" " |
£521.00 |
| TRANS-013/02-A |
" " |
" " |
High B,0.2mm |
" " |
" " |
£345.00 |
| TRANS-013/02-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£685.50 |
| TRANS-013/02-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£923.50 |
| TRANS-013/03-AN |
" " |
Audio Note™ silver |
AN Ultra HiB |
" " |
" " |
£753.50 |
| TRANS-013/03-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£918.00 |
| TRANS-013/02-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£1107.00 |
Driver transformers 1:1 ratio to suit 6BX7, 6DN7 and 6SN7GTB
|
| Order Code |
Suggested Valves |
Winding: Primary - Secondary |
Core material |
Standing Current |
Step-down Ratio |
Price each (exc. vat) |
| TRANS-014 |
6BX7,6DN7,6SN7GTB |
Copper-Copper |
M4 I/E |
20mA |
1:1 |
£111.00 |
| TRANS-014/01-AN |
" " |
" " |
AN Ultra HiB |
" " |
" " |
£397.00 |
| TRANS-014/01-A |
" " |
" " |
High B,0.2mm |
" " |
" " |
£221.00 |
| TRANS-014/01-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£526.00 |
| TRANS-014/01-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£686.00 |
| TRANS-014/02-AN |
" " |
Copper - Audio Note™ silver |
AN Ultra HiB |
" " |
" " |
£521.00 |
| TRANS-014/02-A |
" " |
" " |
High B,0.2mm |
" " |
" " |
£345.00 |
| TRANS-014/02-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£685.50 |
| TRANS-014/02-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£923.50 |
| TRANS-014/03-AN |
" " |
Audio Note™ silver |
AN Ultra HiB |
" " |
" " |
£753.50 |
| TRANS-014/03-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£918.00 |
| TRANS-014/02-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£1107.00 |
Driver transformers 1:1 ratio to suit 437A, 417A or equivalents
|
| Order Code |
Suggested Valves |
Winding: Primary - Secondary |
Core material |
Standing Current |
Step-down Ratio |
Price each (exc. vat) |
| TRANS-016 |
437A,417A or equivalent |
Copper-Copper |
M4 I/E |
30mA |
1:1 |
£111.00 |
| TRANS-016/01-AN |
" " |
" " |
AN Ultra HiB |
" " |
" " |
£397.00 |
| TRANS-016/01-A |
" " |
" " |
High B,0.2mm |
" " |
" " |
£221.00 |
| TRANS-016/01-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£526.00 |
| TRANS-016/01-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£686.00 |
| TRANS-016/02-AN |
" " |
Copper - Audio Note™ silver |
AN Ultra HiB |
" " |
" " |
£521.00 |
| TRANS-016/02-A |
" " |
" " |
High B,0.2mm |
" " |
" " |
£345.00 |
| TRANS-016/02-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£685.50 |
| TRANS-016/02-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£923.50 |
| TRANS-016/03-AN |
" " |
Audio Note™ silver |
AN Ultra HiB |
" " |
" " |
£753.50 |
| TRANS-016/03-B |
" " |
" " |
AN-Perma, 55% Nickel, 0.08mm |
" " |
" " |
£918.00 |
| TRANS-016/02-C |
" " |
" " |
AN Super Perma, 55% Nickel, 0.08mm |
" " |
" " |
£1107.00 |
|
|
