Practical Amplifier Diagrams - 45 Proven Circuits - code 2009

Practical Amplifier Diagrams - 45 Proven Circuits - code 2009

45 amplifier circuit diagrams accompanied with details circuit descriptions. First printed in 1947. A great resource.

207 Pages, containing circuit diagrams, reviews and instructions - black and white print

Contents:

1 Tube 1 Watt AC/DC Amplifier
1 Tube AC/DC "Wireless" Phonograph Oscillator
2 Tube 1.5 Watt AC/DC Amplifier
2 Tube Tube Contact Microphone Amplifier
2 Tube 4 Watt AC Booster Amplifier (transformerless)
2 Tube 5 Watt AC Booster Amplifier
2 Tube Tube Battery Intercommunication Amplifier
2 Tube Tube AC/DC Intercommunication Amplifier
3 Tube 2 Watt Economy AC/DC Amplifier
3 Tube 3 Watt Direct Coupled Amplifier
3 Tube 4 Watt AC Amplifier
3 Tube 4 Watt AC Amplifier (Transformerless)
3 Tube 8 Watt AC Amplifier
3 Tube Quick Heating AC Intercommunication Amplifier
3 Tube 1.5 Watt AC/DC Intercommunication Amplifier
3 Tube 1.5 Watt AC/DC Intercommunication Amplifier
3 Tube Hearing Aid Battery Amplifier
4 Tube 5 Watt AC/DC Amplifier
4 Tube 5 Watt AC/Bat P.A. Amplifier
4 Tube 6 Watt AC High Fidelity Amplifier (high gain)
4 Tube 6 Watt AC High Fidelity Amplifier
4 Tube 6 Watt AC Home Recording Amplifier
4 Tube 10 Watt AC High Fidelity Amplifier
4 Tube 15 Watt AC Low Gain Amplifier
4 Tube 3 Channel Pre-amplifier
5 Tube 10 Watt Class B 6 Volt DC Amplifier
5 Tube 13 Watt AC High Fidelity Amplifier
5 Tube 13 Watt High Fidelity P.A. Amplifier
5 Tube 15 Watt Quick Heating Phonograph Amplifier
5 Tube 35 Watt Transmitter Modulator
5 Tube 30 Watt AC P.A. High Fidelity Amplifier
6 Tube 6 Watt 2 Channel Amplifier
6 Tube 10 Watt 6 Volt AC P.A. Amplifier
6 Tube 10 Watt P.A.High Fidelity Amplifier
6 Tube 12 Watt AC Recording and Playback Amplifier
6 Tube 25 Watt AC high Fidelity P.A. Amplifier
6 Tube 45 Watt AC Fixed Bias Amplifier
7 Tube 14 Watt Recording and Playback Amplifier
7 Tube 20 Watt AC High Fidelity Amplifier
7 Tube 45 Watt AC P.A. Amplifier
8 Tube 12 Watt AC Phonograph Expander and Compressor Amplifier
8 Tube 25 Watt 4 Channel P.A. Amplifier
8 Tube 50 Watt AC Transmitter Modulator
9 Tube 45 Watt P.A. Amplifier
10 Tube 15 Watt Compact AC P.A. Amplifier
11 Tube 75 Watt AC P.A. Amplifier
